Product Details:
Payment & Shipping Terms:
|
| INSULATION: | PVC | Conductor: | Stranded Copper |
|---|---|---|---|
| Rated Voltage: | 450/750v | Certificates: | CE,ROHS,CCC,KEMA And More Other At Request |
| Core: | 1 Core | Size: | 1.5-25mm2 |
| Standards: | GB/T5023-2008 | ||
| High Light: | electrical wire cable,insulated wire cable |
||
BVR 450/750v stranded copper conductor low voltage house wiring cable
Description:
Single core cables with copper conductor , ( solid or stranded ) and insulated with PVC compound. The cables are manufactured according to IEC 60227 60228 or BS 6004 specifications.
Construction:
Conductor : Plain annealed circular copper according to IEC 60228 class 1,2 Insulation : PVC compound rated 70º C or 85º C for continuous operation.
Sheath: PVC compound 70ºC or 90ºC grey or black or as per requirement.
Applications : Building wires fixed installation and laid in pipes for general applications.
Note: Insulation color as per standards or customer requirement
Applications
Used for indoor applications for electric power, lighting and internal wiring in houses or other fixed installation and laid in pipes for general applications.
Standards
International: IEC 60227 IEC 60228,
China: GB/T 12706-91 GB306.1-2001, GB/T18380.3-2001
Other standards such as BS,DIN and ICEA upon request
Technical data
Rated voltage:300/500 V, 300/300V, 450/750V
Max. Conductor Temp. in normal use: 70°C or 90°C
| Nom.Cross-section Area | Thickness of insulation | Mean.O.D. | Min.Insulation resistance at 70℃ | Max.R of conductor at 20℃ | Approx.weight | |
| Lower Limit | Upper Limit | |||||
| mm2 | mm | mm | mm | MΩ*KM | Ω/km | kg/km |
| 1.5 | 0.7 | 2.7 | 3.3 | 0.010 | 12.1 | 21.6 |
| 2.5 | 0.8 | 3.3 | 4.0 | 0.009 | 7.41 | 34.8 |
| 4 | 0.8 | 3.8 | 4.6 | 0.0077 | 4.61 | 50.3 |
| 6 | 0.8 | 4.3 | 5.2 | 0.0065 | 3.08 | 71.2 |
| 10 | 1.0 | 5.6 | 6.7 | 0.0066 | 1.83 | 119 |
| 16 | 1.0 | 6.4 | 7.8 | 0.0050 | 1.15 | 179 |
| 25 | 1.2 | 8.1 | 9.7 | 0.0050 | 0.727 | 281 |
After-service commitment
Shanghai Shenghua Cable (Group) possesses Shenghua tenet "Strive for the Best Enterprise, Produce the Best Product, Provide the Best Service, Establish the Best Brand", insists the policy of quality first, endeavors to achieve high quality and zero defect of goods. Therefore, every client could fully benefit from Shenghua Cable's superior quality and faultless service. Meanwhile, we observe Shenghua spirit of "Do Best, Mutually Win", wish to establish long-term and stable relationship with every client. Hereby, we guarantee that:
1. Customer is God. We will cherish every client, every cooperation by heart.
2. Free pre-sales service. We will provide best proposal for each client.
3. Good sales service. We will provide free relative product operation, maintenance tips and installation commissioning
technical advisory service when establish cooperation relationship with clients.
4. Thoughtful after sales service . Our product are warranted by PICC(People's Insurance Company of China). We will
provide free maintaining and debugging within 12 month after installation(except for the wrong using).
5. We guarantee solve your problems within 24 hours in Shanghai, 72 hours for other district.
Shanghai Shenghua Cable (Group) Co., Ltd.
