3 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard

China 3 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard supplier
3 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard supplier 3 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard supplier 3 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard supplier 3 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard supplier

Large Image :  3 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard

Product Details:

Place of Origin: Shanghai, China
Brand Name: SHANCABLE
Certification: ISO,CE,IEC,TUV,KEMA
Model Number: N2XBY 0.6/1kV

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wooden Drum
Delivery Time: 10 Days
Payment Terms: L/C, T/T
Supply Ability: 100KM/Week
Detailed Product Description
Model Name: STA Armoured Cable Conductor Type: Cu, Copper
Insulation Material: XLPE Rated Voltage: 600/1000V
Armour Type: Galvanized Steel Tape Armoured Sizes: 1~ 630 SQMM
Cores: 2-5 Sheath Material: PVC
Warranty: 2 Years Standards: IEC / BS / IS / VDE
Outer Sheath Color: Black Or As Per Requested
High Light:

armoured power cable

,

armored electrical cable

3 Cores Double Steel Tape Armoured Cable 0.6 / 1kV IEC standard Shanghai Manufacturer

Applications



STA Armored Electric Cable YJV22 4 Core Cable applies to electrical power transmission and distribution lines with AC rated voltage Uo/ U up to and including 0.6/1kV.

For outdoor and indoor installation in damp and wet locations,laid directly in the ground where excessive mechanical stresses are present in sloping and moving terrains and in vertical or inclined laying,as well as in locations susceptible to sliding.



YJ: XLPE insulation

V: PVC insulation

V: PVC sheath

22: Galvanized steel tape armoring

32: Galvanized steel wire armoring



Constructions



Conductor: Plain circular stranded copper conductor, conforms to IEC 60228 class 2

Insulation: PVC/A, XLPE

Inner Covering: PVC

Armoring: Steel Wire, Steel Tape, Aluminum Wire at request

Sheath: PVC/ST2 to IEC 60502, black

Note: Insulation color as per standards or at request



Applications



Used as power distribution and transmission line at rated voltage 0.6/1kV.

Suitable for burying in ground, laying down wells and under water. Able to bear certain axis pulling force.



Standards



International: IEC 60502-1, IEC 60228

China: GB/T 12706.1-2008

Other standards such as BS,DIN and ICEA upon request



Technical data



Rated voltage: 0.6 / 1 kV

Max. Conductor Temp.: normal (70°C), short circuit no more than 5 s (160°C when section-area below 300mm2, 140°C when section-area above 300mm2)

Min. Ambient Temp.: 0°C, after installation and only when cable is in a fixed position

Min. Bending Radius: 20 x cable O.D



Nom. Cross-section of conductor Strands No./Dia. Of Conductor Insulation Thickness Inner Covering Thickness Dia. Of Armor Wire Sheath Thickness Approx. O.D.

Approx.

Weight

Max. D.C Resistance of Conductor (20 ℃) Testing Voltage A.C Current Rating
mm2 pc/mm mm mm mm mm (mm) kg/km Ω /km

kV/

5min

In air (A) In soil(A)
3 × 1.5 1/1.38 0.7 1.0 0.9 1.8 15.8 359 12.1 3.5 20 27
3 × 2.5 1/1.78 0.7 1.0 0.9 1.8 16.8 415 7.41 3.5 26 35
3 × 4 1/2.25 0.7 1.0 0.9 1.8 18.0 611 4.61 3.5 34 45
3 × 6 1/2.76 0.7 1.0 0.9 1.8 19.0 718 3.08 3.5 43 57
3 × 10 7/1.38 0.7 1.0 1.25 1.8 22.0 937 1.83 3.5 60 77
3 × 16 7/1.78 0.7 1.0 1.60 1.8 24.5 1318 1.15 3.5 83 105
3 × 25 7/2.14 0.9 1.0 1.6 1.8 29.2 1707 0.727 3.5 105 125
3 × 35 7/2.52 0.9 1.0 1.6 1.8 32.5 2071 0.524 3.5 125 155
3 × 50 10/2.52 1.0 1.0 1.6 1.9 33.0 2405 0.387 3.5 160 185
3 × 70 14/2.52 1.1 1.0 1.6 2.0 37.0 3084 0.268 3.5 200 225
3 × 95 19/2.52 1.1 1.2 1.6 2.1 43.0 4126 0.193 3.5 245 270
3 × 120 24/2.52 1.2 1.2 2.0 2.3 45.0 4901 0.153 3.5 285 310
3 × 150 30/2.52 1.4 1.4 2.0 2.4 51.0 6365 0.124 3.5 325 345
3 × 185 37/2.52 1.6 1.4 2.0 2.6 56.0 7555 0.0991 3.5 375 390
3 × 240 48/2.52 1.7 1.4 2.5 2.8 62.0 9284 0.0754 3.5 440 450
3 × 300 61/2.52 1.8 1.6 2.5 3.0 67.0 11226 0.0601 3.5 505 515
3 × 400 61/2.97 2.0 1.6 2.5 3.2 74.0 15714 0.0470 3.5 570 575



Certificates



CE, RoHS, CCC, KEMA and more others at request



Packing & Shipping


All cable For exporting are well packed and protected by wooden drum or Wood and Steel Drum.

The packing material is depended on the weight and size of cable.

The good information, manufacture information, and the client's information is firmly printed on each size of drum.

After the well packed cable drums sent to Sea Port, they are loaded into 20 FT container or 40 FT container. All cable drum are firmly fixed by safety belt to make sure, no movement during the sea freight.

The size of the container is chosed according to weight of total loaded goods or as per the client's requirement.



3 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard 03 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard 03 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard 0FAQ

Q: How long does it take to get a quote back?
A: Most quotes are returned within 24 hours, however, if it is for a special construction, it could take more days.

Q: Do you custom package?
A: We strive to meet our customers' needs and therefore have no problem meeting most specifications. We can reel into coils, disposable cartons, special reels, or load your wire and cable into reusable plastic containers. Please check with your sales representative first to verify we can meet your need.

Q: What warranties do your products carry?
A: SHAN cable guarantees that all of our products, wires cables,and more are free from defects. We will take back any product that does not meet the agreed quality by both parties. The specific terms are as follows :
1.We guarantee that we will comply with the requirements of warranty period specified in the contract, that the Goods supplied under the purchase order For Procurement of self-carrying distribution network's cable and wire
2.We will be manufactured under this specification and that the Goods will be new, unused, of the most recent or current models. Once we are selected, we will supply the Goods strictly according to the requirements of the Contract.
3.The warranty shall remain valid for twelve (12) months after the Goods, or any portion thereof as the case maybe, have been delivered to and accepted at the final destination indicated in the SCC, or for eighteen (18) months after the date of shipment from the port or place of loading in the country of origin, whichever period concludes earlier.
4. During the warranty period purchaser may proclaim directly to the manufacturer in the written form or by the agent if there is any problem in Goods quality. The manufacturer will do the repair or replacement in reasonable time, and will bear all the expenses relating to this.

3 Cores Double Steel Tape Armoured Electrical Cable 0.6 / 1kV IEC Standard 3
