Flexible Cable 6sqmm LV 3Core CU / PVC / PVC Rated Electrical Cable Wire Voltage 450/750V

China Flexible Cable 6sqmm LV 3Core CU / PVC / PVC Rated Electrical Cable Wire Voltage 450/750V supplier
Flexible Cable 6sqmm LV 3Core CU / PVC / PVC Rated Electrical Cable Wire Voltage 450/750V supplier Flexible Cable 6sqmm LV 3Core CU / PVC / PVC Rated Electrical Cable Wire Voltage 450/750V supplier Flexible Cable 6sqmm LV 3Core CU / PVC / PVC Rated Electrical Cable Wire Voltage 450/750V supplier Flexible Cable 6sqmm LV 3Core CU / PVC / PVC Rated Electrical Cable Wire Voltage 450/750V supplier

Large Image :  Flexible Cable 6sqmm LV 3Core CU / PVC / PVC Rated Electrical Cable Wire Voltage 450/750V

Product Details:

Place of Origin: Shanghai, China
Brand Name: SHANCABLE
Certification: ISO,CE,IEC,TUV,KEMA
Model Number: RVV

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wooden Drum
Delivery Time: 10 Days
Payment Terms: L/C, T/T
Supply Ability: 100KM/Week
Detailed Product Description
Stranded No/Dia: 84/0.3mm Conudctor: Flexible Copper
Jacket: PVC Cable Sample: Free
Test Voltage: 2500V/5min Jacket Color: According To Customer's Request
High Light:

electrical wire cable

,

insulated wire cable

Flexible Cable 6sqmm LV 3Core CU /PVC/PVC Rated Voltage:450/750V Electrical Cable Wire



1. Description:Single core cables with copper conductor , ( solid, stranded or flexible ) and insulated with PVC compound. The cables are manufactured according to IEC 60227&BS 6004 specifications.

2. Construction:- Conductor : Plain annealed circular copper according to IEC 60228 class 1,2 ,5 and 6.
- Insulation : PVC compound rated 70º C or 85º C for continuous operation

3. Applications : Building wires fixed installation and laid in pipes for general applications

4.Specification:

No.of cores & cross-section area Thickness of insulation Nominal thickness of sheath Av.overall diameter
(mm)
Max.R of conductor at 20oC Min.Insulation resistance at 70oC Approx.weight
Lower limit Upper limit Copper conductor Tinned copper conductor
mm2 mm mm mm mm ohm/km ohm/km M ohm˙km kg/km
3x0.75 0.6 0.8 6.4 8 26 26.7 0.011 70.1
3x1.0 0.6 0.8 6.8 8.4 19.5 20 0.01 82.2
3x1.5 0.7 0.9 8 9.8 13.3 13.7 0.01 116
3x2.5 0.8 1.0 9.6 12 7.98 8.21 0.009 171



After-service commitment

Shanghai Shenghua Cable (Group) possesses Shenghua tenet "Strive for the Best Enterprise, Produce the Best Product, Provide the Best Service, Establish the Best Brand", insists the policy of quality first, endeavors to achieve high quality and zero defect of goods. Therefore, every client could fully benefit from Shenghua Cable's superior quality and faultless service. Meanwhile, we observe Shenghua spirit of "Do Best, Mutually Win", wish to establish long-term and stable relationship with every client. Hereby, we guarantee that:
1. Customer is God. We will cherish every client, every cooperation by heart.
2. Free pre-sales service. We will provide best proposal for each client.
3. Good sales service. We will provide free relative product operation, maintenance tips and installation commissioning
technical advisory service when establish cooperation relationship with clients.
4. Thoughtful after sales service . Our product are warranted by PICC(People's Insurance Company of China). We will
provide free maintaining and debugging within 12 month after installation(except for the wrong using).
5. We guarantee solve your problems within 24 hours in Shanghai, 72 hours for other district.
6. 24 hours hot-line telephone service. We will appoint professional person answer your question timely.
We always firmly believe that " Quality is life line, Service is laissez-passer", which will make us more closer and tight!
