Low Voltage Flexible Conductor Electrical Cable Wire Non - Sheathed House

China Low Voltage Flexible Conductor Electrical Cable Wire Non - Sheathed House supplier
Low Voltage Flexible Conductor Electrical Cable Wire Non - Sheathed House supplier Low Voltage Flexible Conductor Electrical Cable Wire Non - Sheathed House supplier Low Voltage Flexible Conductor Electrical Cable Wire Non - Sheathed House supplier

Large Image :  Low Voltage Flexible Conductor Electrical Cable Wire Non - Sheathed House

Product Details:

Place of Origin: SHANGHAI CHINA
Brand Name: SHAN CABLE
Certification: CE/ROHS/KEMA/CCC
Model Number: RV-90

Payment & Shipping Terms:

Minimum Order Quantity: 1000m
Price: USD 0.33-10.99/M
Packaging Details: 100m/roll
Delivery Time: 15 day
Supply Ability: 80KM/ Day
Contact Now
Detailed Product Description
Size: 0.5-2.5mm Core: Single
Rated Voltage: 300/500v Certificates: CE,ROHS,CCC,KEMA And More Other At Request
Color: Red, White, Blue, Green, Brown, Gray, Black

Low voltage flexible conductor non-sheathed house wiring cables



RV cable has a wide range of applications in the field of industrial power distribution, especially for more demanding flexible installation sites, such as electrical control cabinets, distribution boxes and a variety of low-voltage electrical equipment, can be used for transmission of power, electrical control signals and switching signals . The RV wire and cable adopts a soft structure design with a small bending radius of the conductor and is suitable for a humid and oily installation site.



Descriptions

single-core non-sheathed cables with flexible conductor for internal wiring for a conductor of 90℃  Code designation : 60227 IEC 08 ( International ),RV-90 300/500v(china).

Constructions

1. Conductor : flexible copper conductor , comform to IEC 60228 class 5
2. Insulation : PVC / E

Standards

International : IEC 60227

China : GB / T 5023-2008

Other standards such as BS , DIN and ICEA upon request

Technical data

Rated voltage : 300 / 500 V

Max . Conductor Temp . in normal use : 90℃

Min Bending Radius : 6 x cable O.D

Certificates
CE,ROHS,CCC,KEMA and more others at request



Specifications

Nom.Cross-section Area Thickness of insulation Mean.O.D. Max.R of conductor at 70℃ Min.Insulation resistance at 20℃ Approx.weight
Lower Limit Upper Limit
mm2 mm mm mm m ohm/km ohm˙km kg/km
0.5 0.6 2.1 2.5 0.013 39.0 9.9
0.75 0.6 2.2 2.7 0.011 26.0 13.0
1 0.6 2.4 2.8 0.010 19.5 15.5
1.5 0.7 2.8 3.4 0.009 13.3 21.0
2.5 0.8 3.4 4.1 0.009 7.98 32.5
