House Wiring Cable Supplier CU/PVC/PVC 300/500V Used In Building And Construction.

China House Wiring Cable Supplier CU/PVC/PVC 300/500V Used In Building And Construction. supplier
House Wiring Cable Supplier CU/PVC/PVC 300/500V Used In Building And Construction. supplier House Wiring Cable Supplier CU/PVC/PVC 300/500V Used In Building And Construction. supplier House Wiring Cable Supplier CU/PVC/PVC 300/500V Used In Building And Construction. supplier House Wiring Cable Supplier CU/PVC/PVC 300/500V Used In Building And Construction. supplier

Large Image :  House Wiring Cable Supplier CU/PVC/PVC 300/500V Used In Building And Construction.

Product Details:

Place of Origin: Shanghai, China
Brand Name: SHANCABLE
Certification: ISO,CE,IEC,TUV,KEMA
Model Number: RV

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wooden Drum
Delivery Time: 10 Days
Payment Terms: L/C, T/T
Supply Ability: 100KM/Week
Detailed Product Description
Color Of Insulation: Orange,Red,Yellow,Green,white,black,grey,Brwon,Yellow/Green Material: White PVC
Nominal Area Of Conductor: 0.50mm2 To 240mm2 Test Voltage: 2500V/5min
Conductor Type: Flexible Copper Conductor (class5) Standard: IEC60227*3
Transport: By Container
High Light:

electrical wire cable

,

insulated wire cable

House Wiring Cable Supplier CU/PVC/PVC 300/500V Used In Building And Construction.



Descriptions



Single-core non-sheathed cables with rigid conductor for general purposes

Code designation: 60227 IEC 02/06 (International), RV (China), H07V-K/H05V-K(VDE)



Constructions



①  Conductor: Plain circular Flexible copper conductor, comform to IEC 60228 class 5



②  Insulation: PVC



Applications



In dry rooms, apparatus switch and distribution boards, for fixed installation in conduits, over and under plaster and on insulated supports over plaster. Direct laying in plaster is not permitted.

Standards

International: IEC 60227

China: GB/T 5023-2008

Other standards such as BS,DIN and ICEA upon request



Technical data



Rated voltage:450/750 V,300/500V

Max. Conductor Temp. in normal use: 70℃

Min. Bending Radius: 4 x cable O.D

Certificates

CE, RoHS, CCC, KEMA and more others at request



Specifications







RV 300/500V



Nominal area of conductor No./Dia. Of Conductor Max.O.D Approx.Weight
mm2 mm mm2 kg/km
0.3 16/0.15 2.3 6.4
0.4 23/0.15 2.5 8.1
0.5 16/0.2 2.6 9.1
0.75 24/0.2 2.8 12.2
1.0 32/0.2 3.0 15.1



RV 450/750V



Nominal area of conductor No./Dia. Of Conductor Max.O.D Approx.Weight
mm2 mm mm2 kg/km
1.5 30/0.25 3.4 21.4
2.5 49/0.25 4.1 24.5



RV 450 / 750V



Nominal area of conductor No./Dia. Of Conductor Max.O.D Approx.Weight
mm2 mm mm2 kg/km
4 56/0.20 4.8 51.8
6 84/0.30 6.4 71.4
10 84/0.30 8.0 12.4
16 128/0.4 8.8 173
25 200/0.4 11 268
35 280/0.4 12.5 371
50 400/0.4 14.5 526
70 356/0.5 17 727
95 485/0.5 19 959
120 614/0.5 21 1201
150 765/0.5 23.5 1508
185 944/0.5 26.0 1844
240 1225/0.5 29.5 2420







House Wiring Cable Supplier CU/PVC/PVC 300/500V Used In Building And Construction. 0House Wiring Cable Supplier CU/PVC/PVC 300/500V Used In Building And Construction. 1
