BVV Electrical Cable Wire with Pure Copper or CCA Conductor 300 / 500V Rated Voltage

China BVV Electrical Cable Wire with Pure Copper or CCA Conductor 300 / 500V Rated Voltage supplier
BVV Electrical Cable Wire with Pure Copper or CCA Conductor 300 / 500V Rated Voltage supplier BVV Electrical Cable Wire with Pure Copper or CCA Conductor 300 / 500V Rated Voltage supplier BVV Electrical Cable Wire with Pure Copper or CCA Conductor 300 / 500V Rated Voltage supplier BVV Electrical Cable Wire with Pure Copper or CCA Conductor 300 / 500V Rated Voltage supplier

Large Image :  BVV Electrical Cable Wire with Pure Copper or CCA Conductor 300 / 500V Rated Voltage

Product Details:

Place of Origin: SHANGHAI CHINA
Brand Name: SHAN CABLE
Certification: UL/ROHS/KEMA/CCC
Model Number: BVV

Payment & Shipping Terms:

Minimum Order Quantity: 100m
Price: USD 0.33-7.99/M
Packaging Details: 100m/roll
Delivery Time: 2 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 80000KM/ Day
Contact Now
Detailed Product Description
International Standard: IEC 60227*53 Rated Voltage: 300/500V
Warranty: 2 Years Conductor Temp: 70 Degree
Free Sample: Yes,no Problem Conductor: Pure Copper Or CCA

Manufacturer China BVV Electrical Cable Wire.2Core,3 Core,4Core,5 Core x1.5sqmm,2.5sqmm to 6sqmm



Descriptions


Light PVC Sheathed Cable for fixed wiring.
Code designation: 60227 IEC 10 (International), BVV 300/500V(China)
Constructions
① Conductor: Plain circular solid copper conductor, comform to IEC 60228 class 1
Plain circular stranded copper conductor, comform to IEC 60228 class 2
② Insulation: PVC/C
③ Inner Covering
④ Overall Sheath: PVC type ST4
Note: Insulation color as per standards or at request


Applications


Used as fixed wiring cable of rated voltage 300/500V.
Standards
International: IEC 60227
China: GB/T 5023-2008
Other standards such as BS,DIN and ICEA upon request
Technical data
Rated voltage:300/500 V
Max. Conductor Temp. in normal use: 70℃
Min. Bending Radius: 4 x cable O.D
Certificates
CE, RoHS, CCC, KEMA and more others at request



BVV 300/500V



Nominal area of conductor No./Dia. Of Conductor Max.O.D Approx.Weight
mm2 mm mm2 kg/km
1x0.75 1x1/0.97 4.3 23
1x1.0 1x1/1.13 4.5 26.4
1x1.5(A) 1x1/1.38 4.9 34.6
1x1.5(B) 1x7/0.52 5.2 36.5
1X2.5(A) 1x1/0.85 5.8 46.4
1X4(A) 1x1/2.25 6.4 65.9
1X4(B) 1x7/0.85 6.8 73.7
1X6(A) 1x1/2.76 7.0 91.6
1X10 1x7/1.35 8.8 152.0
2X1.5(A) 2x1/1.38 10.0 109
2X1.5(B) 2x7/0.52 10.5 123
2X2.5(A) 2x1/1.78 11.5 157
2X2.5(B) 2x7/0.68 12.0 172
2X4(A) 2x1/2.25 12.5 205
2X4(B) 2x7/0.85 13.0 222
2X6(A) 2x1/2.76 13.5 265
2X6(B) 2x7/1.04 14.0 286
2X10 2x7/1.35 17.5 471
3X1.5(A) 3x1/1.38 10.5 136
3X1.5(B) 3x7/0.52 11.0 146
3X2.5(A) 3x1/1.78 12.0 190



BVV 300/500V



Nominal area of conductor No./Dia. Of Conductor Max.O.D Approx.Weight
mm2 mm mm2 kg/km
3x2.5(B) 3X7/0.68 12.5 207
3X4(A) 3X1/2.25 13.0 252
3X4(B) 3X7/0.85 13.5 272
3X6(A) 3X1/2.76 14.5 344
3X10 3X7/1.35 19.0 574
4X1.5(A) 4X1/1.38 11.5 164
4X1.5(B) 4X7/0.52 12.0 174
4X2.5(B) 4X7/0.68 13.5 252
4X4(A) 4X1/2.25 14.5 321
4X4(B) 4X7/0.85 15.0 346
4X6(A) 4X1/1.04 16.0 470
4X6(B) 4X7/2.76 17.0 439
5X1.5(A) 5X1/1.38 12.0 192
5X1.5(B) 5X7/0.52 12.5 205
5X2.5(A) 5X1/1.78 14.0 272
5X2.5(B) 5X7/0.68 14.5 292
5X4(A) 5X1/2.25 16.0 397
5X4(B) 5X7/0.85 17.0 418
5X6(A) 5X1/2.76 17.5 518
5X6(B) 5X7/1.04 18.5 550



Packing and shipping

We are capable of meeting the most strict delivery schedules according to per purchase order. Meeting the deadline is always the top priority as any delay in the delivery of cable can contribute to overall project delay and cost overrun.
Cable is supplied in wooden reels, corrugated boxes and coils. Cable ends are sealed with BOPP self adhesive tape and non-hygroscopic sealing caps to protect the cable ends from moisture. The required marking shall be printed with a weather-proof material on the outsides of drum according to customer's requirement.

After-service commitment

Shanghai Shenghua Cable (Group) possesses Shenghua tenet "Strive for the Best Enterprise, Produce the Best Product, Provide the Best Service, Establish the Best Brand", insists the policy of quality first, endeavors to achieve high quality and zero defect of goods. Therefore, every client could fully benefit from Shenghua Cable's superior quality and faultless service. Meanwhile, we observe Shenghua spirit of "Do Best, Mutually Win", wish to establish long-term and stable relationship with every client. Hereby, we guarantee that:
1. Customer is God. We will cherish every client, every cooperation by heart.
2. Free pre-sales service. We will provide best proposal for each client.
3. Good sales service. We will provide free relative product operation, maintenance tips and installation commissioning
technical advisory service when establish cooperation relationship with clients.
4. Thoughtful after sales service . Our product are warranted by PICC(People's Insurance Company of China). We will
provide free maintaining and debugging within 12 month after installation(except for the wrong using).
5. We guarantee solve your problems within 24 hours in Shanghai, 72 hours for other district.
6. 24 hours hot-line telephone service. We will appoint professional person answer your question timely.
We always firmly believe that " Quality is life line, Service is laissez-passer", which will make us more closer and tight!
