XLPE Insulated PVC Sheathed Single Core LSOH Power Cable

China XLPE  Insulated PVC Sheathed Single Core LSOH Power Cable supplier
XLPE  Insulated PVC Sheathed Single Core LSOH Power Cable supplier XLPE  Insulated PVC Sheathed Single Core LSOH Power Cable supplier

Large Image :  XLPE Insulated PVC Sheathed Single Core LSOH Power Cable

Product Details:

Place of Origin: SHANGHAI CHINA
Brand Name: SHAN CABLE
Certification: RoHS/KEMA/TUV/CE/ISO
Model Number: WDZA-YJY WDZ-YJY

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wooden Drum/ Steel wooden Drum / Whole steel Drum
Delivery Time: 7 Days
Payment Terms: L/C, T/T, D/P, D/A
Supply Ability: 38573KM/Day
Detailed Product Description
Product Name: LSHF LSOH Fire Resistant Cable Sheath: PVC Sheathed
Size: 1.5-800mm2 Rated Voltage: 0.6/1kV
Color: Customized Standard: IEC60502 ,IEC60754, IEC61034-1 60331
Packing: Steel Wooden Drum
High Light:

XLPE insulated lsoh power cable

,

Single Core lsoh power cable

,

LSOH Single Core power cable

Environmentally Low Smoke Zero Halogen Cable IEC60502 IEC60754 IEC61034-1 60331



With the development of the society, all the cables have the environmentally friendly features, which can protect the enviorment.



Construction



Conductor: Annealed bare copper solid or strands. The copper wires are formed into final conductor in the stranding machines under strict quality surveillance.



Insulation: Cross linked polyethylene compound is insulated over the conductors by extrusion process.The raw materials and thicknesses of Insulation are maintained as per standards and conform to IEC60502/BS7870 Standards as the case may be.



XLPE:Insulated Power Cable are identified either by colour or by numbers as follows:
No. of cores Identification
Old Colour coding New Colour coding as per different customers. Normally the color as below:
1 Red or Black Brown or Blue
2 Red & Black Brown, Blue
3 Red, Yellow Blue Brown, Black, Grey
4 Red, Yellow, Blue & Black Blue, Brown, Black, Grey
5 Red, Yellow, Blue, Black, Y/G Blue, Brown, Black, Grey & Y/G



Armour : Single core cables are armored with Aluminium Wires or Aluminum Tape armored based on requirement.

Three core: steel wire armored or Steel tape armored.



Outer sheath : Polyene Hydrogen Sheath , LSHO

Standards

International: IEC 60502, IEC 60227 IEC 60331, IEC 61034 60332

China: GB/T 12706-91 GB306.1-2001, GB/T18380.3-2001

Other standards such as BS,DIN and ICEA upon request



Parameters



Type Description Cores Nominal Cross Section

WDZA-YJY

WDZB-YJY

WDZC-YJY

Copper conductor/XLPE insulation Low Smoke Halogen Free or Zero Halogen (LSHF or LSZH) flame-retardant Power Cable 1, 2, 3, 4, 3+1,
5, 4+1, 3+2
1.5~800mm2
WDZA-YJY23 WDZB-YJY23 WDZC-YJY23 Copper conductor/XLPE insulation/Steel Tape Armored Low Smoke Halogen Free or Zero Halogen (LSHF or LSZH) flame-retardant Power Cable 1, 2, 3, 4, 3+1,
5, 4+1, 3+2
1.5~800mm2
WDZA-YJY33 WDZB-YJY33 WDZC-YJY33 Copper conductor/XLPE insulation/Steel Wire Armored Low Smoke Halogen Free or Zero Halogen (LSHF or LSZH) flame-retardant Power Cable 1, 2, 3, 4, 3+1,
5, 4+1, 3+2
1.5~800mm2
WDZA-YJLY WDZB-YJLY WDZC-YJLY Aluminum conductor/XLPE insulation Low Smoke Halogen Free or Zero Halogen (LSHF or LSZH) flame-retardant Power Cable 1, 2, 3, 4, 3+1,
5, 4+1, 3+2
1.5~800mm2
WDZA-YJLY23 WDZB-YJLY23 WDZC-YJLY23 Aluminum conductor/XLPE insulation/Steel Tape Armored Low Smoke Halogen Free or Zero Halogen (LSHF or LSZH) flame-retardant Power Cable 1, 2, 3, 4, 3+1,
5, 4+1, 3+2
1.5~800mm2
WDZA-YJLY33 WDZB-YJLY33 WDZC-YJY33 Aluminum conductor/XLPE insulation/Steel Wire Armored Low Smoke Halogen Free or Zero Halogen (LSHF or LSZH) flame-retardant Power Cable 1, 2, 3, 4, 3+1,
5, 4+1, 3+2
1.5~800mm2



Details



XLPE  Insulated PVC Sheathed Single Core LSOH Power Cable 0

Packaging

XLPE  Insulated PVC Sheathed Single Core LSOH Power Cable 1
