Shenghua YJLV Aluminum Power Cables 40% Cost Savings Vs Copper IEC 60502 Certified

Medium Voltage Single-Core XLPE Insulated Power Cable From 25 sqmm to 800sqmm

Slash Infrastructure Costs Without Sacrificing Reliability: Shenghua’s YJLV Aluminum Cables Deliver 40% Savings​​

​​Engineered for Solar Farms, Grid Upgrades & Harsh Environments​​

As global renewable energy investments surge past ​​$2 trillion annually​​ (IEA 2025), project developers face a critical challenge: balancing budget constraints with uncompromising performance. ​​Shenghua Power Cable​​ solves this equation with ​​YJLV Series Aluminum Conductor Cables​​—​​IEC 60502-certified​​ solutions that reduce costs by ​​40% versus copper cables​​ while matching current-carrying capacity. Validated in 850+ MW of solar installations and rural grid modernization projects, our aluminum-core technology redefines value engineering for sustainable infrastructure.

​​Solar & Grid Applications: Where Shenghua Excels​​

1. ​​Photovoltaic Farms​​:

   • ​​3×150mm² PV Array Cables​​: XLPE insulation withstands ​​90°C continuous heat​​ in desert solar fields (e.g., Saudi Arabia’s NEOM project), while UV-resistant PVC sheathing prevents degradation under intense irradiation
     5
     .
   • ​​Salt-Resistant Armoring​​: Optional stainless steel tape armor neutralizes corrosion in coastal or high-salinity regions like Qatar’s Lusail Solar Park
     6
     .

2. ​​Rural Grid Modernization​​:

   • ​​Direct Burial Durability​​: Withstand soil acidity, moisture, and temperature swings (-30°C to 50°C) for ​​25+ years​​—ideal for ASEAN village electrification projects
     5
     .
   • ​​Faster Installation​​: Class B stranding (IEC 60228) enables ​​30% tighter bending radii​​ than rigid copper cables, accelerating trench deployment
     6
     .

 ​​Technical Superiority: Data-Driven Value​​

 ​​Proven in Extreme Conditions​​

• ​​Middle East Solar Farms​​: Salt-mist armored YJLV cables powering 200MW UAE projects, surviving ​​50°C ambient temps + 85% humidity​​
  6
  .
• ​​Himalayan Grid Upgrades​​: ​​3×185mm² +1×95mm²​​ variants deployed in Nepal at 3,500m elevation, operating flawlessly at ​​-25°C​​
  5
  .
• ​​Off-Grid Mining Operations​​: Aluminum conductors resist vibration fatigue in Chilean copper mines, reducing downtime by ​​22%​​ versus copper alternatives.

 ​​Why Contractors Choose Shenghua YJLV​​

• ​​Certified Performance​​: Dual ​​IEC 60502 + GB/T 12706​​ compliance, with ​​KEMA​​ and ​​CE​​ marks for global acceptance.
• ​​Rapid Customization​​: Tailor conductor sizes (1.5–400mm²), armor (steel/stainless steel), and sheath colors (black/red/yellow-green) in ​​≤7 days​​.
• ​​Zero Halogen Safety​​: FR-PVC sheathing option (IEC 60332-3 Cat. A) for tunnels/urban areas, emitting ​​<15 Dₘ smoke density​​ when exposed to fire
  5
  .

Construction

Conductor: Annealed Aluminum Conductor as per IEC 60228

≤ 6mm2 solid (class 1) or stranded (class 2)

＞ 6mm2 stranded (class 2)

Flexible conductor (class 5) optional.

Insulation: XLPE (Cross-Linked Polyethylene) rated at 90℃

Metallic Screen optional: Copper tape or copper wires screen optional

Sheath: PVC or FR-PVC type ST2 to IEC 60502, black or red or customization

Applications

For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.

Standards

International: IEC 60502, IEC 60228, (IEC 60332-3 for FR-type only)

China: GB/T 12706, (GB/T 18380-3 for FR-type only)

Other standards such as BS, DIN and ICEA upon request

Installation

1. The installation temperature should not over 20℃, If the ambient temperature is lower than 0℃, the cable should be preheated.
2. The bending radius of cable should not less than 8 times.

Technical Data:
