Shenghua XLPE Insulated Power Cable 0.6/1kV | LSZH Sheath & Copper Conductor
| Attribute |
Value |
| Conductor |
Stranded copper conductor |
| Insulation |
XLPE |
| Sheath |
LSZH |
| Test Voltage |
3.5KV/5mins |
| Product name |
XLPE insulated PVC sheathed power cable |
| Core |
Multi-core |
| Corporation |
Shenghua Group |
| Brand |
Sh Cable |
Power the Future with Shenghua XLPE Insulated Power Cable
N2XY POWER CABLE COPPER delivers uncompromising safety and performance for global infrastructure applications.
Why Shenghua XLPE Cable Dominates Critical Power Systems
Shenghua's N2XY Copper Conductor XLPE Insulated Power Cable (0.6/1kV) redefines reliability for fixed electrical installations. Engineered with LSZH (Low Smoke Zero Halogen) sheathing, it combines fire safety with extreme durability—ideal for industrial plants, urban grids, and renewable energy projects where human safety and operational continuity are paramount.
Core Innovations Driving Superior Performance
Triple-Layer Defense Architecture
- Conductor: Stranded copper (IEC 60228 Class 2) ensures optimal conductivity and flexibility
- Insulation: XLPE (cross-linked polyethylene) withstands 90°C continuous operation, 130°C emergencies, and 250°C short circuits (≤5 sec)—outperforming PVC in thermal aging and chemical resistance
- Sheath: LSZH material minimizes toxic fumes during fires, complying with global safety mandates (IEC 60332, IEC 60754)
Rigorous Safety & Compliance
- Certifications: CE, RoHS, KEMA, and custom approvals for BS/DIN/ICEA standards
- Testing: 3.5kV/5min AC voltage test guarantees zero dielectric breakdown
Engineered for Real-World Demands
- Bending Radius: 15× cable OD (multi-core) simplifies installation in ducts or trenches
- Current Capacity: 515A (in soil) for 4×300+1×150mm² configuration—30% higher than industry averages
Technical Superiority in Action: Critical Applications
| Application |
Shenghua Advantage |
| Industrial Plants |
Withstands 90°C continuous load + chemical exposure; LSZH sheath protects personnel |
| Urban Power Grids |
0.0601 Ω/km resistance (4×300mm²) reduces energy loss; direct-burial compatible |
| Renewable Energy Farms |
-40°C to 130°C operational range; resists UV, moisture, and soil corrosion |
Key Specs Spotlight
- 5×50mm² Cable: 0.387 Ω/km resistance, 185A soil current rating, 2.0mm LSZH sheath
- 3×240+2×120mm² Cable: 0.0754 Ω/km resistance, supports 450A underground transmission
Shenghua's Global Leadership: Why Engineers Trust Us
- Manufacturing Scale: 1.3M sqm facility, 5,000+ employees, and ISO 9001/14001/OHSAS 18001 certification ensure batch-to-batch consistency
- Export Excellence: Cables deployed across 60+ countries—from Australian mining ops to Romanian infrastructure
- Responsive Support: MOQ 200 meters, 30% deposit pre-production, wooden drum packaging for damage-free shipping
Technical Specifications
Constructions
- Conductor: Stranded copper conductor, Class 2 as per IEC 60228
- Insulation: XLPE
- Sheath: LSZH
- Test Voltage: 3.5KV/5mins
Applications
The cable is suitable for the fixed laying in the AC 50Hz, for electric transmission.
Standards
- International: VDE0276, IECASTM, JS, BS
- China: GB/T 12706, GB/T 19666
- Other standards such as BS, DIN and ICEA upon request
Certificates
- Rated voltage: 0.6/1kV
- Maximum Conductor Temperature: under normal (90°C), emergency (130°C) or short circuit no more than 5 s (250°C) conditions
- Min. Ambient Temp: 0°C, after installation and only when cable is in a fixed position
- Min. Bending Radius: 20 x cable O.D for single core, 15 x cable O.D for multi core
- CE, RoHS, KEMA and more others at request
Commercial Items
- MOQ: 200m
- Payment terms: 30% T/T before production, 70% T/T before delivery
- Packing: Wooden Iron drum
Detailed Specifications
| Nom. Cross-section of conductor |
Strands No./Dia. Of Conductor |
Insulation Thickness |
Sheath Thickness |
Approx. O.D. |
Approx. Weight |
Max. D.C Resistance of Conductor (20°C) |
Testing Voltage A.C |
Current Rating In air (A) |
Current Rating In soil(A) |
| 5 × 4 |
1/2.25 |
0.7 |
1.8 |
14.5 |
349 |
4.61 |
3.5 |
34 |
45 |
| 5 × 6 |
1/2.76 |
0.7 |
1.8 |
15.8 |
460 |
3.08 |
3.5 |
43 |
57 |
| 5 × 10 |
7/1.38 |
0.7 |
1.8 |
19.0 |
699 |
1.83 |
3.5 |
60 |
77 |
