| Rated Voltage: | 8.7/15kV | Insulation Color: | Nature Or Customization |
|---|---|---|---|
| Core No.: | 1 Or 3 | Conductor: | Stranded Aluminum Conductor |
| Standard: | IEC 60502-2,IEC 60228 | Core Mark: | Color Strip Or Number |
| Cable Mark: | Ink Printing Or Embossing | Packing Style: | 500 To 1000 Meter Per Drum |
| Corporation: | Shenghua Group | Brand: | Sh Cable |
| Highlight: | 21/35kV aluminum XLPE power cable,KEMA-certified seismic-resistant cable,XLPE insulated aluminum power cable |
||
| Attribute | Value |
|---|---|
| Rated Voltage | 8.7/15kV |
| Insulation Color | Nature or Customization |
| Core No. | 1 or 3 |
| Conductor | Stranded Aluminum Conductor |
| Standard | IEC 60502-2, IEC 60228 |
| Core Mark | Color Strip or Number |
| Cable Mark | Ink Printing or Embossing |
| Packing Style | 500 to 1000 meter per drum |
| Corporation | Shenghua Group |
| Brand | Sh Cable |
Shenghua redefines grid resilience with its triple-core aluminum-conductor XLPE cables, engineered to deliver 90°C continuous power for mining, renewables, and seismic zones. Trusted across 60+ countries and compliant with IEC 60502-1, KEMA, and GB/T 12706, these cables merge cost efficiency with disaster-proof reliability.
| Infrastructure | Shenghua Solution | Performance Proof |
|---|---|---|
| Offshore Wind Farms | Salt-resistant XLPE + hermetic seals | 0.164Ω/km (3×185mm²); 90°C operation in humidity |
| Mining Operations | FR-PVC sheath + rock-impact resistance | 73.5kV/5min dielectric test; 30-year design life |
| Urban Smart Grids | EMI-shielded copper tape screen | Zero interference in Surabaya's IoT grid (2023-present) |
| Component | Specification |
|---|---|
| Conductor | Aluminum Conductor as per IEC 60228, Class 2 Circular or Shaped conductor |
| Insulation | XLPE (Cross-Linked Polyethylene) rated at 90°C, many color optional |
| Metallic Screen optional | Copper tape or copper wires braiding optional |
| Sheath | PVC or FR-PVC type ST2 to IEC 60502, black or red or customization |
| Nom. Cross-section of conductor (mm²) | Insulation Thickness (mm) | Sheath Thickness (mm) | Approx. O.D. (mm) | Approx. Weight (kg/km) | Max. D.C Resistance of Conductor (20°C) (Ω/km) | Testing Voltage A.C (kV/5min) | Current Rating In air (A) | Current Rating In soil (A) |
|---|---|---|---|---|---|---|---|---|
| 1×35 | 4.5 | 2.0 | 24 | 587 | 0.868 | 30.5 | 180 | 195 |
| 1×50 | 4.5 | 2.0 | 25 | 674 | 0.641 | 30.5 | 215 | 230 |
| 1×70 | 4.5 | 2.0 | 27 | 768 | 0.443 | 30.5 | 265 | 285 |
| 1×95 | 4.5 | 2.0 | 29 | 902 | 0.320 | 30.5 | 325 | 345 |
| 1×120 | 4.5 | 2.0 | 30 | 1022 | 0.253 | 30.5 | 375 | 395 |
| 1×150 | 4.5 | 2.0 | 32 | 1162 | 0.206 | 30.5 | 425 | 445 |
| 1×185 | 4.5 | 2.0 | 34 | 1307 | 0.164 | 30.5 | 490 | 500 |
| 1×240 | 4.5 | 2.0 | 36 | 1548 | 0.125 | 30.5 | 580 | 590 |
| 1×300 | 4.5 | 2.0 | 39 | 1815 | 0.100 | 30.5 | 665 | 670 |
| 1×400 | 4.5 | 2.5 | 42 | 2170 | 0.0778 | 30.5 | 785 | 780 |
| 1×500 | 4.5 | 2.5 | 45 | 2556 | 0.0600 | 30.5 | 910 | 895 |
| 1×630 | 4.5 | 2.5 | 50 | 3248 | 0.0469 | 30.5 | 1060 | 1010 |
| 1×800 | 4.5 | 2.6 | 55 | 3790 | 0.0367 | 30.5 | 1230 | 1160 |
| 1×1000 | 4.5 | 2.8 | 59 | 4527 | 0.0291 | 30.5 | 1410 | 1300 |
| 1×1200 | 4.5 | 2.9 | 63 | 5202 | 0.0247 | 30.5 | 1540 | 1410 |
| Nom. Cross-section of conductor (mm²) | Insulation Thickness (mm) | Sheath Thickness (mm) | Approx. O.D. (mm) | Approx. Weight (kg/km) | Max. D.C Resistance of Conductor (20°C) (Ω/km) | Testing Voltage A.C (kV/5min) | Current Rating In air (A) | Current Rating In soil (A) |
|---|---|---|---|---|---|---|---|---|
| 3×25 | 4.5 | 2.5 | 50 | 2072 | 1.20 | 30.5 | 110 | 110 |
| 3×35 | 4.5 | 2.5 | 53 | 2334 | 0.868 | 30.5 | 130 | 130 |
| 3×50 | 4.5 | 2.5 | 55 | 2598 | 0.641 | 30.5 | 160 | 155 |
| 3×70 | 4.5 | 3.0 | 58 | 2895 | 0.443 | 30.5 | 195 | 190 |
| 3×95 | 4.5 | 3.0 | 63 | 3462 | 0.320 | 30.5 | 235 | 225 |
| 3×120 | 4.5 | 3.0 | 66 | 3888 | 0.253 | 30.5 | 275 | 225 |
| 3×150 | 4.5 | 3.0 | 70 | 4416 | 0.206 | 30.5 | 310 | 285 |
| 3×185 | 4.5 | 3.0 | 74 | 4935 | 0.164 | 30.5 | 355 | 325 |
| 3×240 | 4.5 | 3.5 | 79 | 5712 | 0.125 | 30.5 | 415 | 380 |
| 3×300 | 4.5 | 3.5 | 84 | 6577 | 0.1000 | 30.5 | 475 | 430 |
| 3×400 | 4.5 | 3.7 | 89 | 8081 | 0.0778 | 30.5 | 555 | 485 |
We are capable of meeting the strictest delivery schedules according to per purchase order. Meeting the deadline is always the top priority as any delay in the delivery of cable can contribute to overall project delay and cost overrun.
Cable is supplied in wooden reels, corrugated boxes and coils. Cable ends are sealed with BOPP self-adhesive tape and non-hygroscopic sealing caps to protect the cable ends from moisture. The required marking shall be printed with a weather-proof material on the outsides of drum according to customer's requirement.
Shanghai Shenghua Cable (Group) possesses Shenghua tenet "Strive for the Best Enterprise, Produce the Best Product, Provide the Best Service, Establish the Best Brand", insists the policy of quality first, endeavors to achieve high quality and zero defect of goods. Therefore, every client could fully benefit from Shenghua Cable's superior quality and faultless service.
We observe Shenghua spirit of "Do Best, Mutually Win", wish to establish long-term and stable relationship with every client. Hereby, we guarantee that:
We always firmly believe that "Quality is life line, Service is laissez-passer", which will make us more closer and tight!
A: Most quotes are returned within 24 hours, however, if it is for a special construction, it could take more days.
A: SHAN cable guarantees that all of our products, wires cables,and more are free from defects. We will take back any product that does not meet the agreed quality by both parties. The specific terms are as follows:
A: Wire and cable is our forte, however, we also sell connectors, cable assemblies and cable tools to name just a few. Our products serve numerous markets all over the world.
